Followup to yesterday's post: https://www.reddit.com/r/LocalLLaMA/comments/1sy7srk/. Comments asked for perplexity, KL divergence, asymmetric K/V combos, and a 64K data point. Ran them overnight. Same M5 Max, same Qwen 3.6-35B-A3B Q8, same TheTom TurboQuant fork (feature/turboquant-kv-cache).
Quality (perplexity + KL divergence on wikitext-2)
For u/milpster and u/Karyo_Ten. Context size 4096, since the canonical 512 doesn't fill enough KV cache to surface cache-quantization effects. f16 saves the baseline logits via --kl-divergence-base, then each quant run computes KL against that.
| Cache | PPL | KL vs f16 | Top-1 token agreement |
|---|---|---|---|
| f16 | 5.7438 | baseline | n/a |
| q8_0 | 5.7433 | 0.0016 | 98.64% |
| turbo3 (~4.9x) | 5.8092 | 0.0199 | 93.93% |
| turbo4 (~3.8x) | 5.7810 | 0.0131 | 95.28% |
q8_0 KV is essentially free at this depth. The PPL delta is -0.0005, well inside the ±0.036 stderr. KL is 0.0016. The quantized cache picks the same top-1 token as f16 98.6% of the time. The worry from yesterday's comments was "what does this cost in quality." At 4k context, it's noise.
turbo3 costs about 1% PPL increase and 5 percentage points of top-token disagreement, with KL roughly 12x q8_0. turbo4 sits between, in line with its lower compression ratio. Quality cost scales with compression, no surprises.
Asymmetric K/V (depth sweep)
For u/Sabin_Stargem and my own untested caveat from yesterday. Decode tok/s, same llama-bench flags as the symmetric sweep:
| Depth | q8_0 K / turbo4 V | q8_0 K / turbo3 V | f16 K / turbo4 V |
|---|---|---|---|
| 0 | 82.9 | 81.8 | 72.8 |
| 8K | 75.4 | 75.6 | 16.9 |
| 32K | 66.0 | 63.2 | 8.6 |
| 128K | 41.0 | 38.2 | 2.8 |
| 256K | 27.1 | 25.0 | skipped |
| 512K | 16.5 | 14.8 | skipped |
-ctk q8_0 -ctv turbo4 is the standout. At 256K it matches yesterday's symmetric q8_0 throughput (pp 128 vs 124, tg 27.1 vs 26.6), and it fits 512K where symmetric q8_0 OOM'd. So you get q8_0-grade prefill behavior with turbo4-grade context ceiling. Sabin's hypothesis that V compresses cheap and K compresses expensive looks right on the throughput side. Quality side I'd want a PPL run on the asym combos to fully close the loop.
-ctk q8_0 -ctv turbo3 does the same trick but with worse decode. Tighter V quant taxes the generation side more.
-ctk f16 -ctv turbo4 is broken on this fork on Metal. The FlashAttention kernel doesn't fast-path that K/V type combination, so it falls back to a generic dequant-then-attention path. At 8K it's 34x slower than symmetric f16. At 128K it's 78x slower (4.1 t/s pp). Cells past 128K weren't worth completing. Don't use this combo.
64K row
For u/ocarina24. Filling the 32K to 128K gap on the prefill curve. All seven configs at depth 65536:
| Cache | pp512 | tg128 |
|---|---|---|
| f16 (symmetric) | 602.0 | 59.8 |
| q8_0 (symmetric) | 479.2 | 57.9 |
| turbo3 (symmetric) | 469.8 | 49.9 |
| turbo4 (symmetric) | 418.0 | 55.2 |
| q8_0 K / turbo4 V | 468.2 | 55.9 |
| q8_0 K / turbo3 V | 465.6 | 52.6 |
| f16 K / turbo4 V | 8.3 | 4.9 |
Two things stood out. First, the prefill curves are nearly converged at 64K. turbo3 (470) is within 2% of q8_0 (479). Yesterday's data showed turbo3 actually pulling ahead by 128K (253 vs 245), so the bandwidth-bound regime kicks in somewhere between 64K and 128K on this hardware. Earlier than I'd estimated. Second, the asymmetric q8_0/turbo* rows track symmetric q8_0 prefill closely at this depth too. Same story as the deeper rows.
What I take from all of this
Updated cache-type recommendation from yesterday:
- Coding agents (deep context, lots of generated tokens): -ctk q8_0 -ctv turbo4 is the new pick. q8_0 quality on K, turbo4 savings on V, fits 512K.
- RAG or batch QA (heavy prefill, short answers): same combo, or symmetric turbo3 at the deepest depths.
- Pure 1M context maxing: still symmetric turbo3, only thing that fits.
- Short interactive (under 32K): f16 if memory allows, else q8_0. Quality cost is genuinely zero.
Caveats
- PPL was at 4096 context. Quality at deeper contexts, where the cache is more saturated, might tell a different story.
- Asymmetric quality numbers are still pending. Throughput data argues V-side compression is cheap, but I haven't measured KL or PPL on the asym combos yet.
- f16 K + turbo* is a kernel fallback on this fork on Metal. Verify before assuming this combo works on other backends.
- Single hardware data point (M5 Max, 128 GB). Crossover depths and the prefill/decode split likely shift with memory bandwidth and GPU core count.
Still in flight
- u/GCoderDCoder. Aider Polyglot pass for f16, turbo3, and turbo4 (q8_0 was 62.2% earlier this week, n=225). Each Polyglot run is about 6 to 12 hours, so it's a few nights serial. Running later this week.
- u/noctrex. Wider quant types (q4_0, q4_1, iq4_nl, q5_0, q5_1) extending the depth sweep. After Aider.
- u/Able_Librarian1569. Same sweep on a non-MoE non-DeltaNet model for transferability. After the wider quant types.
Same offer as yesterday. If you have non-M5-Max Apple Silicon and want to run a slice of this matrix, drop your numbers below or DM me. Happy to send the raw llama-bench and llama-perplexity output for anyone who wants to dig into the per-cell stats.
Full writeup with the methodology and the per-cell stderr numbers: https://llmkube.com/blog/turboquant-m5-max-quality-and-asymmetric
